64W Custom Solenoid

Name: 64W Custom Solenoid
Brand: DASON
Price: 5 USD

Wholesale 64W Custom Solenoid from china suppliers

Brand Name : DASON

Model Number : Dsn-4038X-01

Certification : ISO9001

Place of Origin : China

MOQ : 500

Price : 5~9USD

Payment Terms : T/T,

Supply Ability : 300000

Delivery Time : 30day

Packaging Details : Carton packing

Type : Pressure Regulators

Relative humidity : 20%-85%

usage : suck battery equipment

Stroke(mm) : 8mm

Install Style : screw

Service Life : 500 Thousand Times

Contact Now

Vending Machine Solenoid Lock Smart Door Lock Solenoid Can Be Customized With Long Life Solenoid

Product Description

1.Name (P / N): BS-4038X-01 shared bikes electromagnet lock
2. Standard test conditions:
2.1 Ambient temperature:-20 ℃ ~ + 45 ℃, 5% ~ 95% RH
2.2 Relative humidity:-20 ℃ ~ + 65 ℃, 5% ~ 60% RH
2.3 Rated voltage: DC24V
2.4 Power Consumption: 64W (DC24V, R = 9Ω ± 10%)
2.5 Working cycle: On: Off = 0.05 seconds: 0.35 seconds (maximum power-on time: 3 seconds power-on frequency ED 12%)
3. Appearance:no damage, crack, rust, surface stain
4. Electrical characteristics:
4.1 Working voltage: DC24V ± 10%
4.2 Potence: DC24V Gauss value: ≥1120GS
4.3 Insulation resistance: DC500V, ≥50MΩ (between the coil and the skeleton)
4.4 high voltage: AC700V 50 / 60Hz-1 second, maximum leakage current 1mA (between coil and case)
5.0 Life: ≥200,000 times (DC24V, on for 0.05 seconds, off for 0.35 seconds as one time, load )

Weight		Packaging Details		Shipment Details
N.W.(KG)	G.W.(KG)	Product Size(mm)	Carton Box Size(mm)	20GP	40GP	40HQ
0.3	0.4	273053	350310180	/	/	/

Product dimension drawing

Smooth and flat surface, saving energy, safe and reliable

Size: 126*121*17 (mm), 5000N-10000N super suction, with force power on and without force power off

Durable and easy to operation

Durable steel construction, copper wound coils, high temperature resistant, with two depth 20mm M10 mounting teeth at the bottom,easy to install and operation.

Packing	Carton, standard dimension(LWH): 350310180, customize according to customer's requirement
Product Size(mm)	372620
Product Weight	N.W.(KG): 0.096	G.W.(KG): 0.096
Shipping:	Sea /air freight, Express (DHL, UPS, TNT, FEDEX, EMS etc).
Supply Ability:	5000 pieces per week
MOQ:	2 PCS; small orders can be acceptable if we have stocks of this product
Our Products	circular holding solenoid; square holding solenoid; open frame solenoid; tubular solenoid; keep solenoid; lock solenoid

OEM/ODM is welcome

11 years of designing and producing experience
CE, ROHS, ISO9001, UL certification
Good quality, best service, competitive price
Warmly welcome your visit to our factory

Product Features

Small in size
Big in force
With force power on and without force power off
Easy to operate
Epoxy filled
IP65
Wide range of application
10 years of designning and producing experience
OEM/ODM is welcomed
